Descriere
‘- LCD monitor, 1-3 channels channels in Standard or Cabrera format with base line setting
– High resolution thermal printer (8 dots/mm): hardcopy 1-3 channels real time with possibility to print a millimetric grid
– Manual or automatic recording
Technical details
• Power supply: internal rechargeble Ni-Cd batteries
• AC/DC adapter: 100-240V, 50-60 Hz; 200mA
• Battery autonomy: 2.5 hours
• Applied part: CF type
• Input impedance: > 100 Mohm
• Frequency response: 0.05: 145hz
• Cmrr: > 91 dB Time constant: > 3.2 s
• Acquisition: 12 bit 800 samples/sec/channel-isochrome
• Leads: 12 standard or Cabrera
• Sensitivity: 5mm/mV; 10mm/mV; 20mm/mV ±5%
• Scrolling speed: 5mm/s; 10mm/s; 25mm/s; 50mm/s
• Signal memory: 10s for each lead
• Printer: thermal printer 8 dots/mm, paper 58 mm
• Filters:
– muscles tremors 35Hz digital
– power line interferences 50-60 Hz
– digital high pass 0.5Hz digital
• Defibrillation protection: internal
• Display/Hardcopy: 1/3 channel (3M)
• Size 240 x 160 x 65 mm
• Weight: 1.5 kg
• Made in Italy
Accessories included
• 6 électrodes d’extrémités pour le torse
• 1 rouleau de papier
• 1 flacon de gel
• Batterie
• Câble patient
• 4 électrodes d’extrémités
• Manuel (GB, IT)
• Guide d’utilisation rapide: GB, ES, IT
