Platform scale IFB

lei 3.590,00 – lei 10.290,00

High-resolution scale in heavy version with EC type approval [M], now also up to [Max] 600 kg

Golește
SKU: IFB Categorie:

Descriere

  • Tough industry standard suitable for use in harsh industrial applications
  • Platform: Weighing plate stainless steel, painted steel base, protection against dust and water splashes IP65, silicone-coated aluminium load cell.
  • Display device: Superior display size, digit height 52 mm for the easy reading of weighing results, even under poor lighting conditios,
  • Benchtop stand incl. wall mount for display device as standard
  • Level indicator and levelling feet for precise levelling of the scale, fitted as standard, to give the most accurate weighing result
  • (checkweighing): Input of an upper/lower limit value. A visual and audible signal assists with portion division, dispensing or grading
  • of weights and piece counts
  • Hold function: When the weighing conditions are unstable, a stable weight is calculated determining an average value
  • Protective working cover included with delivery

STANDARD OPTION FACTORY
Adjusting program (CAL): For quick setting of the balance's accuracy. External adjusting weight required.
Data interface RS-232: To connect the balance to a printer, PC or network
GLP/ISO log: with weight, date and time. Only with KERN printers, see Accessories
Piece counting: Reference quantities selectable. Display can be switched from piece to weight.
Totalising level A: The weights of similar items can be added together and the total can be printed out.
Weighing with tolerance range: Upper and lower limiting can be programmed individually, e. g. sorting and portioning.
Vibration-free weighing: (Animal weighing program) Vibrations are filtered out so that a stable weight is obtained.
IP 65 protection in accordance with DIN EN 60529:Designed for temporary contact with liquids. Use a damp cloth for cleaning. Dustproof.
Universal mains adapter: with universal input and optional input socket adapters for EU, GB
Strain gauge: An electrical resistor strip that is glued to an elastic deforming body made of aluminium. As the strain gauge is mechanically deformed its resistance value changes, allowing
Parcel shipment via courier. Ready for dispatch in 1 day
Pallet shipment via freight forwarder.Ready for dispatch in 2 days

only IFB 600K-1M

DAkkS calibration possible. The time required for DAkkS calibration is specified in the pictogram.
Analog Data Interface
Rechargeable battery pack: rechargeable set
Verification possible. The time required for verification is specified in the pictogram.
Model
Weighing
capacity
[Max]
kg
Readability

[d]
g

Verific.
value
[e]
g
Minimum
load
[Min]
g
Min. piece
weight
(Normal)
g/piece
Weighing
plate
W×D×H
mm
Option
Verification
Option
DAkkS
Calibration
Certificate
IFB 3K-4
3
0,1


2
230×230×110
0
1 ✓
IFB 6K-4S
6
0,2


2
230×230×110
0
1 ✓
IFB 6K-4
6
0,2


2
300×240×110
0
1 ✓
IFB 10K-4
15
0,5


5
300×240×110
0
1 ✓
IFB 10K-4L
15
0,5


5
400×300×128
0
1 ✓
IFB 30K-3
30
1


10
400×300×128
0
1 ✓
IFB 60K-3
60
2


10
400×300×128
0
1 ✓
IFB 60K-3L
60
2


20
500×400×130
0
1 ✓
IFB 100K-3
150
5


50
500×400×130
0
1 ✓
IFB 100K-3L
150
5


50
650×500×142
0
1 ✓
IFB 300K-2
300
10


100
650×500×142
0
1 ✓
IFB 600K-2
600
20


200
800×600×200
0
1 ✓
Dual-range balance switches automatically to the next largest weighing range [Max.] and readout [d].
IFB 6K-3SM
3 | 6
1 | 2
1 | 2
20 | 40
2
230×230×110
1 ✓
1 ✓
IFB 6K1DM
3 | 6
1 | 2
1 | 2
20 | 40
2
300×240×110
1 ✓
1 ✓
IFB 15K2DM
6 | 15
2 | 5
2 | 5
40 | 100
5
300×240×110
1 ✓
1 ✓
IFB 15K2DLM
6 | 15
2 | 5
2 | 5
40 | 100
5
400×300×128
1 ✓
1 ✓
IFB 30K5DM
15 | 30
5 | 10
5 | 10
100 | 200
10
400×300×128
1 ✓
1 ✓
IFB 60K10DM
30 | 60
10 | 20
10 | 20
200 | 400
10
400×300×128
1 ✓
1 ✓
IFB 60K10DLM
30 | 60
10 | 20
10 | 20
200 | 400
20
500×400×130
1 ✓
1 ✓
IFB 150K20DM
60 | 150
20 | 50
20 | 50
400 | 1000
50
500×400×130
1 ✓
1 ✓
IFB 150K20DLM
60 | 150
20 | 50
20 | 50
400 | 1000
50
650×500×142
1 ✓
1 ✓
IFB 300K50DM
150 | 300
50 | 100
50 | 100
1000 | 2000
100
650×500×142
1 ✓
1 ✓
IFB 600K-1M
300 | 600
100 | 200
100 | 200
2000 | 4000
200
800×600×200
1 ✓
1 ✓
Note: For applications that require verification, please order verification at the same time, initial verification at a later date is not possible. Verification at the factory, we need to know the full address of the location of use.

Informații suplimentare

Greutate 25 kg
Dimensiuni Nu se aplică
Kern Model

IFB 100K-3, IFB 100K-3L, IFB 10K-4, IFB 10K-4L, IFB 150K20DLM, IFB 150K20DM, IFB 15K2DLM, IFB 15K2DM, IFB 300K-2, IFB 300K50DM, IFB 30K-3, IFB 30K5DM, IFB 3K-4, IFB 600K-1M, IFB 600K-2, IFB 60K-3, IFB 60K-3L, IFB 60K10DLM, IFB 60K10DM, IFB 6K-3SM, IFB 6K-4, IFB 6K-4S, IFB 6K1DM
filter_battery_operated

0
filter_platform_length

23, 24, 30, 40, 50, 60
filter_platform_width

23, 30, 40, 50, 65, 80
filter_weight_capacity

15, 150, 3, 30, 300, 6, 60, 600
filter_class_iii

1
